The interstitium at the developing nephron in the fetal kidney during advanced pregnancy — a microanatomical inventory
Molecular and Cellular Pediatrics volume 9, Article number: 17 (2022)
A series of noxae can evoke the termination of nephron formation in preterm and low birth weight babies. This results in oligonephropathy with severe consequences for health in the later life. Although the clinical parameters have been extensively investigated, little is known about the initial damage. Previous pathological findings indicate the reduction in width of the nephrogenic zone and the lack of S-shaped bodies. Current morphological investigations suggest that due to the mutual patterning beside the forming nephron, also its structural neighbors, particularly the interjacent interstitium, must be affected. However, beside the findings on integrative and mastering functions, systematic microanatomical data explaining the configuration of the interstitium at the developing nephron in the fetal kidney during advanced pregnancy is not available. Therefore, this work explains the typical features.
The generated data depicts that the progenitor cells, nephrogenic niche, pretubular aggregate, and mesenchymal-to-epithelial transition are restricted to the subcapsular interstitium. During the proceeding development, only the distal pole of the renal vesicles and comma- and S-shaped bodies stays in further contact with it. The respective proximal pole is positioned opposite the peritubular interstitium at the connecting tubule of an underlying but previously formed nephron. The related medial aspect faces the narrow peritubular interstitium of a collecting duct (CD) ampulla first only at its tip, then at its head, conus, and neck, and finally at the differentiating CD tubule. The lateral aspect starts at the subcapsular interstitium, but then it is positioned along the wide perivascular interstitium of the neighboring ascending perforating radiate artery. When the nephron matures, the interstitial configuration changes again.
The present investigation illustrates that the interstitium at the forming nephron in the fetal kidney consists of existing, transient, stage-specific, and differently far matured compartments. According to the developmental needs, it changes its shape by formation, degradation, fusion, and rebuilding.
The clinical experiences with preterm and low birth weight babies demonstrate that the developing kidneys are particularly vulnerable from mid to late pregnancy. As well as malnutrition, diabetes and vitamin deficiency of the mother as insufficiency of the placenta, along with hyperoxia and drugs, can evoke the termination of nephron formation, which leads to severe consequences for health in the later life [1,2,3,4]. Pathological findings indicate that the noxae target the outer cortex of the fetal kidney. In its external nephrogenic zone, the reduction of its vertical width  and the loss of here occurring S-shaped bodies  were registered. In the subjacent maturation zone, a reduced number of glomeruli and the rise of atypical glomeruli with an extended Bowman’s space and a shrunken glomerular tuft were observed .
The reduction of the nephrogenic zone  and the lack of S-shaped bodies  in the fetal human kidney are signs that the early links in the chain of nephron formation are broken. Although these massive pathological alterations have been detected, it is currently unknown, whether the neighboring structures such as the earlier stages of nephron anlage, the renal capsule covering, the stock of mesenchymal progenitor cells, the ureteric bud derived collecting duct ampullae, and the interstitium including the sprouting of microvessels are collaterally affected. However, it is of great importance to have a clear understanding of the intactness and the respective damage, since the development of a nephron is not an isolated and autonomously running process. In fact, it depends on intact tissue and cell-to-cell interactions [8, 9] such as the spatial and temporal exchange of morphogenic proteins [10, 11] and the mutual patterning with its structural neighbors .
Little consideration for the progress of nephron development has received the establishing stroma (Greek) or even called interstitium (Latin). It directs not only the interplay between the ureteric bud-derived tips at the collecting duct tubules and the surrounding nephrogenic mesenchymal progenitor cells during the process of induction but also various subsequent molecular interactions [13, 14]. For the rodent kidney, it was shown that the ablation of the FOXD1+ progenitor cells leads to a reduction of branching at the terminal tips of the collecting duct tubules, an uncontrolled expansion of the progenitor cells, an abnormal development of the renal capsule, and a severe alteration in the vascular patterning, which results in a reduced number of nephrons [15, 16]. Furthermore, it was demonstrated that the disturbed microRNA biogenesis in FOXD1+ progenitor cells by the loss of Dicer activity causes multifaceted abnormalities in the developing nephron .
Regarding the interstitium as a mastering instance, it requires special attention, when the initial traces left by the noxae impairing nephrogenesis are investigated in the kidneys of preterm and low birth weight babies. However, it has not been explored by which cell biological mechanism the FOXD1+ progenitor cells control the process of nephron formation and at which cellular or molecular level the noxae show an interference with it. Most surprisingly, the screening of relevant literature revealed that neither data dealing with the precise location of the FOXD1+ progenitor cells at the transient stages of nephron anlage nor data about the expansion of the interstitium at the forming nephron in the fetal human kidney during advanced pregnancy is available. Therefore, to support the search for initial traces left by the impairment of nephrogenesis, an inventory of the interstitium at the forming nephron, seen from a microanatomical perspective, was made.
Material and methods
To obtain a systematic morphological picture about the interstitium at the forming nephron, it is recommended to follow the successive stages of nephron anlage such as the nephrogenic niche, pretubular aggregate, renal vesicles, comma- and S-shaped bodies, and the maturing nephron. In a fetal kidney during advanced pregnancy, the formation of a nephron starts in the nephrogenic zone, which extends along the entire inner side of the renal capsule. Damage during the histological preparation of this particular region must be prevented. For this reason, a fetal kidney is held only on the hilum, and the touching of the renal capsule with fine forceps has to be avoided. Further on, for obtaining comparable perspectives in the histological sections, a fixed kidney is cut from the renal capsule towards the papilla of a lobe. Following this, the section plane lines along the axis of vertically running collecting duct (CD) tubules and perpendicular to the renal capsule .
For the shown illustrations, specimens of the fetal human kidneys are of gestational age between week 16, 18, and later. They were selected from the stock of preparations used for the course of microscopic anatomy for medical students at the University of Regensburg in Germany. These stages are insofar of special interest, because up until birth, the majority of nephrons is formed.
According to routine methods, the tissue blocks were preserved in paraformaldehyde solution and embedded in paraffin wax. Then, sections of 5 µm thickness were cut and stained with hematoxylin–eosin solution for analysis by an optical microscope. Screening of the stained sections was performed by a Leica DM750 microscope (Leica Microsystems, Wetzlar, Germany). The stages of nephron anlage were analyzed with a HI Plan 63 × /0.75 objective lens. Images were taken with a Basler microscopy pulse 5.0 camera (Basler AG, Ahrensburg, Germany). The analyzed specimens had a normal anatomical look and were of good histological preservation. Renal cysts or other pathological alterations were not visible. Each of the selected images in the shown illustrations was selected as the most suitable from a series of at least 5 comparable specimens.
More than 3000 images were available, which had been analyzed for an earlier performed investigation dealing with the shaping of the nephron [19, 20]. From this stock, those representative images were selected, which illustrate the basic stages of initial nephron formation including the expansion of the related interstitium. This is located in the space between the individual stages of nephron anlage and the respective covering tissues. The different sites of the expanding interstitium were allocated to specific structures (Table 1) and labeled by individual symbols (Table 2).
In order to depict the temporal and spatial alterations of the interstitium, beside the photographic illustrations, a series of graphical sketches almost true to scale were produced. To meet the defined criteria, the borders between the individual stages of nephron anlage and their covering tissues were marked 1:1 by hand. In a further step, the generated contours of the interstitium were scanned, edited, and processed by the design program CorelDRAW X7 (Corel Corporation, Munich, Germany). The same program was used for inserting the necessary labels and for obtaining information about the metric parameters in the microscopic images or produced sketches. Finally, to visualize the interstitial changes, mounted image plates were produced. As it is indicated, the proximal pole (fixed point) of the currently forming stage of nephron anlage rests next to the connecting tubule of a previously developed nephron. Since the space for development is occupied at the proximal pole, its distal pole (mobile point) shifts while the expansion is in the vertical direction. Thereby, it postpones radially the overlying structures including the pool of progenitor cells and the renal capsule.
To illustrate the individual structural features of the interstitium between the inner side of the renal capsule and the tip of the CD ampulla, immunohistochemical labeling on sections of neonatal rabbit kidney was performed as it was earlier described . For the present investigations, the cryosections were incubated with monoclonal anti-collagen type 3 antibody (Calbiochem, Schwalbach, Germany). The same specimens were used to demonstrate the ultrastructure of the interface at the CD ampulla tip. The special fixation and contrasting for the analysis in the transmission electron microscopy have been performed by 5% glutaraldehyde buffered with 0.15 M sodium cacodylate, pH 7.4 containing additionally either 1% tannic acid (Sigma-Aldrich Chemie, München, Germany), or 0.1% cupromeronic blue (Santa Cruz, Heidelberg, Germany).
Interstitium as an integrating element
In the fetal human kidney during advanced pregnancy, the formation of new nephrons is restricted to the nephrogenic zone. Covered by the renal capsule (Fig. 1a–c), it consists of side-by-side aligned nephrogenic compartments (Table 1). In each of them, the initial development of a nephron can be observed. It starts in a determined sequence with the transient stages of nephron anlage and continues with the terminal differentiation of the maturing nephron in the subjacent maturation zone. When a transverse line is drawn at the section border between the head and conus of the neighboring collecting duct (CD) ampulla, a nephrogenic compartment is subdivided (Fig. 2a). In the upper district of progenitor cell recruitment, which is seen during the further development as a constant prone rectangle, the mesenchymal nephrogenic progenitor cells meet the epithelial progenitor cells, which are contained in the tip of the CD ampulla, at the nephrogenic niche. As a result of this interaction, first the pretubular aggregate arises, and then, the mesenchymal to epithelial transition takes place (Fig. 2b). This again announces the rising of the primitive renal vesicle (Fig. 2c and d). Due to the vertical elongation of the CD ampulla, the primitive renal vesicle remains in the area of nephron shaping, which is represented during the further development by an expanding quadrate. Here, the formation of the mature, extending, and extended renal vesicles (Fig. 3a–c) and the comma- (Fig. 3d) and S-shaped bodies (Fig. 4a–c) occurs. Then, in the subjacent maturation zone, the functional differentiation of the nephron proceeds (Fig. 4d).
When the arrangement of the interstitium is analyzed, beside the actual contours and the stage-specific location of the forming nephron, also the structural neighbors in a nephrogenic compartment have to be considered (Table 1). At the top, it is covered by the renal capsule (Fig. 1a–c), at the medial aspect by the ureteric bud derived CD ampulla, at the base by the connecting tubule of a previously developed nephron, and at the lateral aspect by a perforating radiate artery. Thus, the available space between the actual stage of nephron anlage and its structural neighbors reflects the current arrangement of the interstitium. However, during the running developmental process, not only the shape of the forming nephron but also the constellation with the structural neighbors is altering. For example, the forming nephron increases in size, takes progressive shapes, shifts between its structural partners, evolves proximal and distal poles, and shows asymmetrical forms at its medial and lateral aspects. In parallel, also the CD ampulla and the perforating radiate artery vertically elongate. Meanwhile, a network arises between the forming nephron and its structural neighbors, which contains, for example, collagen type 3 as a stabilizing compound of the extracellular matrix (Fig. 1b).
Interstitium privatum in the renal capsule
As it was mentioned, the top of a nephrogenic compartment is covered by the renal capsule (Table 1, Fig. 1). It represents an organ-specific kind of the connective tissue. The capsula fibrosa is externally situated, consists of several strata, and protects the growing kidney against inappropriate influences. On microscopic specimens, one can see that numerous fibroblasts occur between the transversely lining layers of collagen bundles (Fig. 1a). Inside the renal capsule, numerous arterial, venous, and lymphatic vessels are visible. The vertically ascending perforating radiate arteries reach the inner side of the renal capsule for joining the Rete capillare capsulare (Fig. 3b). From the neonatal rabbit kidney, it is further known that the collagen in the capsula fibrosa is specifically stacked. Histochemical label revealed, for example, that the external bundles are not stained by tannic acid, while the internal bundles are intensely labeled (Fig. 1c).
The subjacent tunica muscularis contacts the nephrogenic zone. Here, numerous myofibroblasts and atypical and typical smooth muscle cells are noticed (Fig. 1a). Electron microscopy revealed that a part of these cells is covered by a distinct basal lamina, while others show only a faint glycocalyx (Fig. 1c). Further on, at the inner side of the renal capsule and next to the external part of the nephrogenic zone, the neighboring cells establish numerous contacts via cell projections so that the intra- and extracellular space between the cell projections represents a complex tunnel system (Fig. 1d and e). It may serve the transport and distribution of interstitial fluid and to keep the balance of fluid pressure between the renal capsule and the nephrogenic zone.
Interstitial peculiarities between the renal capsule and the tip of a CD ampulla
Although it looks unspectacular in the optical microscope, a series of data indicates that the interstitial space between the inner side of the renal capsule and the tip of the CD ampulla is specially structured (Table 1; Fig. 1b and c).
The transverse mesenchymal cell layers: In the fetal human kidney, the distance between the tip of a CD ampulla and the inner side of the renal capsule is not accidental but has a vertical width of only 30 µm. Between them, the interstitial and nephrogenic progenitor cells are contained. It is striking that the innermost layer of the nephrogenic progenitor cells does not touch but is rather separated by a clear interface from the tip of the CD ampulla (Fig. 1a). At this specific site, the nephrogenic niche is visible.
The vertical microfibers: In the fetal human kidney and, for example, in the neonatal rabbit kidney, the distinct distance between the inner side of the renal capsule and the tip of a CD ampulla is caused by a special mounting. Immunohistochemical label for collagen type 3 in the neonatal rabbit kidney depicts extracellular microfibers. These originate at the inner side of the renal capsule and cross first the stromal and then the nephrogenic progenitor cell layers for the link with the basal lamina at the tip of a CD ampulla (Fig. 1b).
Interstitial fronts at the niche, pretubular aggregate, mesenchymal-to-epithelial transition, and primitive renal vesicle
The meeting between the innermost layer of the nephrogenic mesenchymal progenitor cells and the epithelial progenitor cells contained in the tip of a CD ampulla indicates the precise coordinates of a nephrogenic niche (Figs. 1a and 2a). However, a special feature is that the bodies of the two kinds of progenitor cells do not touch. Instead, these are separated by the clear interface (Fig. 1c). For the kidney of neonatal rabbit, it was further demonstrated that the tip of a CD ampulla is covered by a striking basal lamina. Improved contrasting of specimens by tannic acid (Fig. 1d) or cupromeronic blue (Fig. 1e), for the purpose of transmission electron microscopical analysis, additionally showed that the extracellular matrix within the interface is composed by textured properties. Finally, a concise feature is that single projections of the nephrogenic mesenchymal progenitor cells are enveloped in a specific sleeve of extracellular matrix. By this construction, they vertically cross the interstitial interface to penetrate the basal lamina and to contact via tunneling nanotubes the basal plasma membrane of the epithelial progenitor cells, which are integrated in the tip of a CD ampulla.
After induction by morphogenic molecules, the nephrogenic mesenchymal progenitor cells, which are located at the niche, become angular, migrate, and aggregate first along the tip and then the head of the CD ampulla. As a result, the tear drop-like pretubular aggregate arises (Fig. 2a). It represents a specialized interstitial cell construct, which separates only in part from the overlying nephrogenic mesenchymal progenitor cell layer. While its thin distal end remains in contact with the overlying nephrogenic progenitor cells, its broad end further expands towards the connecting tubule of a previously developed nephron. Due to the typical shape and the distinct position of the pretubular aggregate, its interstitial surrounding is built up asymmetrically. Most of its lateral part is exposed to the subcapsular interstitium, which is located at the inner side of the renal capsule. In contrast, the clear interface is visible between the medial part of the pretubular aggregate and along the tip and head of the CD ampulla. Strikingly, the lateral part at the proximal end of the pretubular aggregate is positioned opposite the perivascular interstitium of a vertically lining perforating radiate artery. The mid of its proximal end faces the peritubular interstitium at the connecting tubule of a previously developed nephron. Determining for the future development, the medial part of its proximal end shows an adhesion at the section border between the head and conus of the CD ampulla.
Typical signs for the mesenchymal-to-epithelial transition (MET) are noticed only at the proximal end of the pretubular aggregate (Fig. 2b). The first polar cells are seen opposite to the cone, which is formed between the peritubular interstitium at the connecting tubule of a previously developed nephron and the perivascular interstitium at the perforating radiate artery. At the same time, the medial part at the proximal end of the pretubular aggregate expands the adhesion at the CD ampulla. This site reflects the future physiological connection between the connecting tubule of the presently forming nephron and the prospective collecting duct tubule.
The morphogenesis of the primitive renal vesicle is first recognized as an open clamp at the proximal end of the pretubular aggregate (Fig. 2c). A circle of polarized cells becomes visible, when the primitive renal vesicle is established (Fig. 2d). Although a small lumen is yet recognized, its distal pole remains connected with the overlying pretubular aggregate. In this situation, the lateral part of the pretubular aggregate is positioned near the subcapsular interstitium, while the lateral aspect of the primitive renal vesicle encounters the perivascular interstitium of the perforating radiate artery. Its proximal pole stays near the peritubular interstitium at the connecting tubule of a previously developed nephron. However, at the medial aspect of the primitive renal vesicle, the adhesion expands at the section border between the head and conus of the CD ampulla. As a consequence, the clear interface lining between the CD ampulla and the medial part of the pretubular aggregate is interrupted at the site of adhesion.
Interstitial features at the mature, extending, and extended renal vesicles
Regarding the microanatomical situation, the subcapsular interstitium accompanies very early steps of nephron formation such as the recruitment of progenitor cells, the process of nephron induction, the formation of the pretubular aggregate, the mesenchymal to epithelial transition, and the arise of the primitive renal vesicle (Fig. 2c–d). However, while the CD ampulla elongates vertically, the primitive renal vesicle starts to separate at its distal pole from the overlying pretubular aggregate. At the same time, it is translocated from the district of progenitor cell recruitment to the subjacent area of nephron shaping. Henceforth, the installation at the medial aspect of the developing renal vesicle is bordered not anymore by the head but by the upper conus of the CD ampulla. At its lateral aspect, the renal vesicle faces yet the radially lining perforating radiate artery. Its distal pole is fixed near the proximal end of the overlying pretubular aggregate, while its proximal pole stays next to the connecting tubule of a previously developed nephron.
The development from the primitive to the mature renal vesicle coincides with a transverse but only partial separation from the pretubular aggregate. In parallel, the adhesion at the section border between the head and conus of the CD ampulla proceeds (Fig. 3a). The separation is first recognized as a narrow transverse cleft. It starts at the end of the clear interface and the initial site of adhesion, and it continues up to the center of the pretubular aggregate. At a later time, it can be observed that the arising cleft is invaded by interstitial cells. At the adhesion site, the connection between the future connecting tubule and the CD ampulla is under work. Surprisingly, the laterally located cells at the distal pole of the mature renal vesicle stay, for a moment, connected with the pretubular aggregate via a two-layered progenitor cell strand serving the progressive recruitment with progenitor cells. Initially, only a close adhesion is noticed between the medial aspect of the mature renal vesicle and the upper conus of the CD ampulla. Then, it is replaced by a narrow cleft, which expands vertically. This is formed due to a cone-shaped interstitial process, which originates in part from the perivascular interstitium of the perforating artery and in part from the peritubular interstitium at the connecting tubule of a previously formed nephron.
At the extending renal vesicle, one can observe that the future connecting tubule is perforating the epithelium of the CD ampulla at the border between its head and conus (Fig. 3b). Furthermore, it is registered that the cleft between its distal pole and the proximal end of the pretubular aggregate extends transversely. Especially remarkable, the lateral part of the distal pole at the extending renal vesicle is still connected with the overlying pretubular aggregate via the two-layered progenitor cell strand. The medial cell strand lines to the mid at the proximal end, while the lateral strand extends to the lateral part of the pretubular aggregate. It is noticed that the lateral cell strand is located at the perivascular interstitium of the perforating radiate artery. Further on, it crosses the subcapsular interstitium including the transverse progenitor cell layers to reach the inner side of the renal capsule. In parallel, between the upper conus of the CD ampulla and the medial aspect of the extending renal vesicle, an elongation of the narrow vertical interstitial cleft is recognized.
While the extended renal vesicle establishes, the tubule anlage expands vertically and laterally (Fig. 3c). At its distal end, the epithelium of the future connecting tubule is connected with the CD ampulla. In the lumen near the proximal pole, the inner epithelial fold becomes visible. This causes the interstitial cleft, which is seen between the tubule anlage and the laterally located progenitor cell strand, to elongate first in an oblique and then in a vertical direction. The entire lateral aspect of the extended renal vesicle is exposed to the perivascular interstitium of the perforating radiate artery. The proximal pole of the extended renal vesicle faces the peritubular interstitium at the connecting tubule of a previously developed nephron. From here, the interstitium invades as a narrow vertical cleft between the conus of the CD ampulla and the medial aspect of the extended renal vesicle.
Interstitial constellation at the comma-shaped body
A special but to date unexplored meaning has the interstitium at the developing comma-shaped body (Fig. 3d). In this phase, beside the elongation of the tubule anlage and the extension of the epithelial folds, the proximal–distal positioning and the defoliation of the arising glomerulus can be observed. Due to the appearance of new contours, parts of the surrounding interstitium disappear, while others retreat or are rebuilt. Interestingly, the progenitor cell strand at the distal pole dissolves, so that the connection between the comma-shaped body and the pretubular aggregate is lost. As a result, the interstitial cleft, located between the tubule anlage and the progenitor cell strand, is fused with the perivascular interstitium of the neighboring perforating radiate artery. At the lateral aspect of the comma-shaped body, precisely between the lateral fold and the tubule anlage, a vertical interstitial cleft develops. It ends at the turn up of the inner fold. This is a clear morphological sign that the glomerulus is starting to defoliate. The future Bowman’s capsule (lateral leg of the lateral fold) faces the perivascular interstitium of the perforating radiate artery. The proximal pole is now located opposite the peritubular interstitium at the connecting tubule of a previously developed nephron. Between the conus of the CD ampulla and the medial aspect of the comma-shaped body, the narrow vertical interstitial cleft further expands. At the connection site between the future connecting tubule and the conus of the CD ampulla, it changes direction to follow the peritubular interstitium at the developing tubule portions towards the geometric center of the comma-shaped body.
Interstitial characteristics at the S-shaped body
During the formation of the early S-shaped body, the physiological link between the connecting tubule and the CD ampulla is completed (Fig. 4a). At this site, an interstitial cone becomes visible. It is bordered at the top by the proximal end of the overlying pretubular and the subcapsular interstitium and by the laterally situated perivascular interstitium of the perforating radiate artery and the peritubular interstitium of the presently forming connecting tubule. Between the conus of the CD ampulla and the medial aspect of the S-shaped body, the narrow vertical interstitial cleft is extended. It lines up to the peritubular interstitium, which surrounds inside the S-shaped body the elongating connecting, distal, intermediate, and proximal tubule portions. At its lateral aspect, the peritubular interstitium of the extending distal and intermediate tubule portions is fused with the perivascular interstitium of the perforating radiate artery. Importantly, the transverse cleft further prolongs at the deep lateral aspect. It opens up between the overlying proximal tubule portion and the subjacent visceral podocyte cell layer of the arising glomerulus. Moreover, one can observe that the cells, which originate from the perivascular interstitium of the perforating radiate artery, invade the transverse cleft. This is a morphological sign that the capillary loops and the intra- and the extraglomerular mesangium are starting to develop. The proximal pole of the S-shaped body is represented by the developing Bowman’s capsule. It is facing at its medial part the peritubular interstitium of a previously developed connecting tubule and at its lateral part the perivascular interstitium of the perforating radiate artery.
During development of the mid S-shaped body, at its proximal pole, the Bowman’s capsule and the Bowman’s space expand. Furthermore, the podocytes develop a typical cobblestone-like appearance (Fig. 4b). In the overlying transverse cleft, beside the numerous capillaries, the formation of the intraglomerular mesangium and the arise of the afferent and efferent arterioles are recognized. At the opening of the transverse cleft, the close topological relation between the perivascular interstitium of the perforating radiate artery and the glomerular tuft is obvious. At the medial aspect of the S-shaped body, it is noticed that a certain distance is formed between the conus of the CD ampulla and the tubule portions. The interjacent space is filled by a loose peritubular interstitium.
Interstitial transition from the nephrogenic zone to the maturation zone
The late S-shaped body as the last transient stage of nephron anlage stays positioned perpendicular to the renal capsule. It demonstrates a morphological segmentation along its proximal–distal axis (Fig. 4c). At the proximal pole, the typical morphological features of the glomerulus appear. For example, the Bowman’s capsule is becoming flat, the Bowman’s space is clearing, and the podocytes show now their typical shape. Further numerous glomerular capillaries become visible, while a broadening of the intraglomerular mesangium occurs. At the medial aspect, the Bowman’s capsule is located near the conus and neck of the CD ampulla and also along the differentiating collecting duct tubule. However, the elongating tubule portions are separated from the neck and conus of the CD ampulla by a newly formed but faint peritubular interstitium. At the lateral aspect, the situation is different, since the connecting and distal tubule portions face the perivascular interstitium of the perforating radiate artery.
Due to the ongoing radial extension of the nephrogenic zone, the late S-shaped body is leaving the area of nephron shaping for the further development in the maturation zone (Fig. 4d). Its distal pole, which is seen at the tip head of the CD ampulla, is positioned near the subcapsular interstitium. At the proximal pole and in its interior, the arising glomerulus and the meandering tubule portions are covered by a faint peritubular interstitium. In this region, single strands of extracellular matrix are noticed, which line in vertical direction. At the meandering tubule portions, one can recognize that within their coves, a filigree interstitium arises. Occasionally, long thin cells with an extended but flat nucleus are here noticed. These are similar to the telocytes.
Interstitial features of the outer renal cortex
Covered by the renal capsule, the interstitium of the outer renal cortex in the fetal kidney during advanced pregnancy is located between the parenchymal structures of the arising nephrons and the developing collecting duct tubules . It consists of a network of organo-typical extracellular matrix, in particular microfibers, proteoglycans, and other special glycoproteins [22,23,24]. At this stage, distinctly different and far matured progenitor cells such as fibroblasts, fibrocytes, myofibroblasts, dendritic cells, macrophages, lymphocytes, and granulocytes are integrated . These are surrounded by the interstitial fluid, which contains electrolytes, nutrition, metabolites, respiratory gas, waste, hormones, cytokines, growth factors, and morphogenic molecules. Additionally, important parts of the interstitium are the arterial, venous, and lymphatic vessels and the site-specific innervation . In contrast to the adult kidney, the low vascularization in the outer cortex of the fetal human kidney during advanced pregnancy suggests a major role for hypoxic physiological conditions during the process of nephron formation .
The interstitium in the renal cortex of the adult kidney was earlier divided into the peritubular and periarterial interstitium and into the glomerular and extraglomerular mesangium . However, due to the complexity of the developing structures, the interstitial configuration in the outer cortex of the fetal human kidney during advanced pregnancy is not comparable. Recent publications and the here shown microscopic images (Figs. 1, 2, 3 and 4) depict that the contained interstitium is heterogenous, and that it is facing not only the covering renal capsule [18, 21, 24, 29] but also the underlying pool of progenitor cells, the transiently developing stages of nephron anlage, the maturing nephrons, the elongating collecting duct (CD) ampullae, and the differentiating collecting duct tubules [30,31,32].
Interstitial source at the developing nephron
A lesser-known but very special interstitial configuration is noticed between the inner side of the renal capsule and the tip of the CD ampulla. The space available has an average width of only 30 µm (Fig. 1a) . Although it is small and looks not particularly spectacular, it was demonstrated that the here occurring interstitial and nephrogenic progenitor cells are stored, sorted, and promoted for the prospective development [34, 35]. Immunohistochemistry revealed that along the inner side of the renal capsule, one layer of stromal cells is positioned, while underneath one to two layers of nephrogenic progenitor cells occur. Although the innermost layer faces the tip of the CD ampulla, it is separated by a striking interstitial interface (Fig. 1c–e). At the niche, the transversely lining progenitor cell layers are crossed by vertically lining extracellular microfibers. These can be labeled, for example, by soybean lectin or antibodies recognizing collagen type 3 as a typical molecular compound of the local extracellular matrix (Fig. 1b) [22, 36]. For the neonatal rabbit kidney, it was further shown that the vertical microfibers are both static and under conversion, since the extracellular matrix-stabilizing tissue transglutaminase 2 (Tgase2) and the matrix-degrading metalloproteinase 9 (MMP9) are co-expressed at this site . Especially remarkable are the ultrastructural features of the interface at the tip of a CD ampulla (Fig. 1c–e) [18, 38,39,40] and the here expressed extracellular matrix glycoproteins . Especially interesting are the projections of the nephrogenic mesenchymal cells, which cross the interstitial matrix within individual sleeves to contact the basal aspect of the epithelial progenitor cells contained in the tip of a CD ampulla [42, 43]. Undeniably, the observed features collectively indicate a highly specialized interstitial microenvironment, which provides the driving support for the initial process of nephron formation .
Translocation between interstitial workbenches
The data depicted in Fig. 5 and Tables 1 and 2 demonstrates that the interstitium at a developing nephron is not centered but distributed among various sites. For this to occur, the requirement is that the expanding interstitium adapts and also alters in accordance to the altering shapes of the nephron and its neighboring structures. Additionally, based on the developmental progress observed, a spatial shifting between the different structures has taken place. This can be registered first by the appearance of the nephrogenic niche, by the aggregation of the pretubular aggregate, mesenchymal to epithelial transition, and then by the formation of the primitive renal vesicle (Figs. 2a–c and 5a–c). These stages are restricted to the district of progenitor cell recruitment. Especially remarkable is the fact that they are always first positioned next to the tip and then to the head of the CD ampulla.
However, due to the partial separation of the primitive renal vesicle, the following process of translocation produces a change in the backdrop. Therefore, the mature, extending, and extended renal vesicles (Figs. 3a–c and 5d–f) and comma- (Figs. 3d and 5g–i) S-shaped bodies (Figs. 4a–c and 5j–l) develop in the underlying area of nephron shaping. Thereby, these stages are facing the elongating conus of the CD ampulla. Lastly, the maturing nephron is positioned in the subjacent maturation zone next to the differentiating collecting duct tubule (Fig. 4d). Recent investigations additionally demonstrated that each of the listed stages exhibits a different shape, is recognized within personal coordinates, and is facing individual parts of the structural neighbors [12, 19, 20]. This again shows that each stage of nephron anlage is exposed to a typical claim of the interjacent interstitium, which can exhibit existing, evolving, transient, degrading, or lasting properties (Fig. 5; Tables 1 and 2).
Narrow interstitial cleft at the medial aspect of the developing nephron
From the kidneys of preterm and low birth babies, it is known that noxae provoke the reduction in width of the nephrogenic zone . Although it has not been closely investigated, one must assume that the loss of tissue concerns not only the stages of nephron anlage but also the structural neighbors such as the CD ampullae, the sprouting microvessels, the establishing interstitium, and probably also the renal capsule . As a consequence, it is highly important to develop a deeper understanding of these details, when the interstitium is seen as an instance that masters the formation of a nephron or when this process is harmed by the noxae impairing nephrogenesis [4, 14, 21, 24].
Particularly striking is the narrow interstitial relation between the CD ampulla and the medial aspect of the developing nephron. At the tip and head of the CD ampulla, the nephrogenic progenitor cells and the medial part of the pretubular aggregate face the clear interface (Figs. 1a, 2, and 5a and b) . While the primitive renal vesicle develops, the interface is interrupted by its adhesion at the section border between the head and conus of the CD ampulla. Recent findings from different groups have shown that this serves the primary linking with the future connecting tubule [45,46,47]. During the ongoing development, the mature, extending, and extended renal vesicles (Figs. 3a–c and 5c–f) face only the upper conus of the CD ampulla, while the comma- (Figs. 3d and 5g–i) and S-shaped bodies (Figs. 4a–c and 5j–l) are additionally situated at the lower conus and neck and even at the upper part of the differentiating collecting duct tubule. Most interestingly, in parallel to the formation of the nephron, a steady elongation of the interjacent interstitial cleft is observed. However, not only the vertical course of the narrow interstitial cleft is impressive but also its arrangement between nearly congruent surfaces. These are provided mainly by the conus of the CD ampulla and the medial aspect of the actual stage of nephron anlage. For the neonatal rabbit kidney, it was demonstrated that the composition of the here situated fibrous extracellular matrix is not homogenous but differs along the various sectors at the CD ampulla . It appears that the narrow interstitial cleft is part of a slide bearing, which is best suited for the short and targeted exchange of morphogenic proteins.
Open interstitial flank at the lateral aspect of the developing nephron
Completely different is the interstitial situation at the distal pole, lateral aspect, and proximal pole of the forming nephron. While the renal vesicles arise, the contained tubule anlage elongates so that finally the inner epithelial fold becomes visible (Fig. 3a–c). This causes that the interstitial invasion at the transverse cleft, which is seen between the distal pole of the renal vesicle and the proximal end of the pretubular aggregate, changes direction to become an oblique interstitial pocket. When the comma-shaped body is forming (Figs. 3d and 5g), the progenitor cell strand is dissolving so that the earlier connection between the distal pole of the renal vesicles and the pretubular aggregate is lost (Figs. 3c and 5d–f). As a consequence, the interstitium within the oblique pocket is fused with both the subcapsular interstitium and the perivascular interstitium of the neighboring perforating radiate artery. Thus, the entire lateral aspect of the S-shaped body (Figs. 4a–c and 5j–l) and of the maturing nephron (Fig. 4d) is henceforth exposed to the perivascular interstitium of the perforating radiate artery. Regarding this special structural relation, it is most likely that a punctual disturbance of these perivascular interstitial cells , which invade the S-shaped body at its lateral aspect, may cause the earlier described pathological damage on the developing glomeruli such as the shrunken glomerular tuft and the expanded Bowman’s capsule . In the future, it is of great importance to understand whether the depicted interstitial constellation is the subject of an integrating or a mastering function .
The interstitium at the developing nephron in the fetal human kidney during advanced pregnancy is a fundamental but largely unexplored part of the nephrogenic zone. This work sheds light and provides the first microanatomical insights reported up to date. The analysis indicates that the interstitium at the forming nephron has a complex structure, which consists of existing, transient, stage-specific, and differently far matured compartments. Precise explanations, clear illustrations, and scaled sketches inform about the respective position. Thus, the created structural basis enables henceforth to investigate the subject in detail. In particular, the search for early traces left by noxae impairing nephrogenesis in preterm and low birth weight babies is supported.
Availability of data and materials
The data sets generated and/or analyzed during the current study are not publicly available due to ongoing research but are available from the corresponding author on reasonable request.
Stritzke A, Thomas S, Amin H, Fusch C, Lodha A (2017) Renal consequences of preterm birth. Mol Cell Pediatr 4(1):2
Dyson A, Kent AL (2019) The effect of preterm birth on renal development and renal health outcome. NeoReviews 20(12):e725–e736
Luyckx VA, Brenner BM (2020) Clinical consequences of developmental programming of low nephron number. Anat Rec (Hoboken) 303(10):2613–2631
Hoogenboom LA, Wolfs TGAM, Hütten MC, Peutz-Kootstra SMF (2020) Prematurity, perinatal inflammatory stress, and the predisposition to develop chronic kidney disease beyond oligonephropathy. Pediatr Nephrol 36(7):1673–1681
Sutherland MR, Gubhaju L, Moore L, Kent AL, Dahlstrom JE, Horne RSC, Hoy WE, Bertram JF, Black MJ (2011) Accelerated maturation and abnormal morphology in the preterm neonatal kidney. J Am Soc Nephrol 22:1365–1374
Rodriguez MM, Gomez AH, Abitbol CL, Chandar JJ, Duara S, Zilleruelo GE (2004) Histomorphogenetic analysis of postnatal glomerulogenesis in extremely preterm infants. Pediatr Dev Pathol 7(1):17–25
Black MJ, Sutherland MR, Gubhaju L, Kent AL, Dahlstrom JE, Moore L (2013) When birth comes early: effects on nephrogenesis. Nephrology (Carlton) 18(3):180–182
Nagalakshmi VK, Yu J (2015) The ureteric bud epithelium: morphogenesis and roles in metanephric kidney patterning. Mol Reprod Dev 82:151–166
Short KM, Smyth IM (2020) Branching morphogenesis as a driver of renal development. Anat Rec (Hoboken) 303(10):2578–2587
Oxburgh L, Muthukrishnan SD, Brown A (2017) Growth factor regulation in the nephrogenic zone of the developing kidney. Results Probl Cell Differ 60:137–164
Rad NK, Aghdami N, Moghadasali R (2020) Cellular and molecular mechanisms of kidney development: from the embryo to the kidney organoid. Front Cell Dev Biol 8:183
Minuth WW (2021) The mutual patterning between the developing nephron and its covering tissues - valid reasons to rethink the search for traces left by impaired nephrogenesis. Mol Cell Pediatr 8(1):9
Kobayashi A, Mugford JW, Krautzberger AM, Naimann N, Liao J, McMahon AP (2014) Identification of a multipotent self-renewing stromal progenitor population during mammalian kidney organogenesis. Stem Cell Report 3(4):650–662
Rowan CJ, Sheybani-Deloui S, Rosenblum ND (2017) Origin and function of the renal stroma in health and disease. Results Probl Cell Difer 60:205–229
Hum S, Rymer C, Schaefer C, Bushnell D, Sims-Lucas S (2014) Ablation of the renal stroma defines its critical role in nephron progenitor and vascular patterning. PLoS ONE 9(2):e8840
Rowan CJ, Li W, Martirosyan H, Erwood S, Hu D, Kim YK, Sheybani-Deloui S, Mulder J, Blake J, Chen L, Rosenblum ND (2018) Hedgehog-GLI signaling in Foxd1-positive stromal cells promotes murine mephrogenesis via TGFβ signaling. Development 154(13):dev159947
Phua YL, Chu JYS, Marrone AK, Bodnar AJ, Sims-Lucas S (2015) Renal stromal miRNAs are required for normal nephrogenesis and glomerular mesangial survival. Physiol Rep 3(10):e12537
Minuth WW, Denk L (2014) Structural links between the renal stem/progenitor cell niche and the organ capsule. Histochem Cell Biol 141(5):459–471
Minuth WW (2020) Shaping of the nephron - a complex, vulnerable, and pooely explored backdrop for noxae impairing nephrogenesis in the fetal human kidney. Mol Cell Pediatr 7(1):2
Minuth WW (2021) Microanatomy of the developing nephron in the fetal human kidney during late gestation. Ann Anat 236:151705
Levinson RS, Batourina E, Choi C, Vorontchikhina M, Kitajewki J, Mendelsohn CL (2005) Foxd1 - dependent signals control cellularity in the renal capsule, a structure required for normal renal development. Development 132(3):529–539
Fleischmajer R, Jacobs L, Perlish JS, Katchen B, Schwartz E, Timpl R (1992) Immunochemical analysis of human kidney reticulin. Am J Pathol 140(5):1225–1235
Lipp SN, Jacobson KR, Hains DS, Schwarderer AL, Calve S (2021) 3D mapping reveals a complex and transient interstitial matrix during murine renal development. J Am Soc Nephrol 32(7):1649–1665
Weiss AC, Rivera-Reyes R, Englert C, Kispert A (2020) Expansion of the capsular stroma, ureteric branching defects and cryptorchism in mice with Wilms tumor 1 gene deletion in the stromal compartment of the developing kidney. J Pathol 252:290–303
Kaissling B, Le Hir M (2008) The renal cortical interstitium: morphological and functional aspects. Histochem Cell Biol 130:247–262
Russell PS, Hong J, Windsor JA, Itkin M, Philips ARJ (2019) Renal lymphatics: anatomy, physiology, and clinical implications. Front Physiol 10:251
Gerosa C, Fanni D, Faa A, Van Eyken P, Ravarino A, Fanos V, Faa G (2017) Low vascularization of the fetal kidney suggests a mojor role for hypoxia in human nephrogenesis. Int Urol Nephrol 49(9):1621–1625
Lemley K, Kriz W (1991) Anatomy of the renal interstitium. Kidney Int 39:370–381
Kobayashi K (1978) Fine structure of the mammalian renal capsule: the atypical smooth muscle cell and its functional meaning. Cell Tissue Res 195(3):381–394
Bülow RD, Boor P (2019) Extracellular matrix in kidney fibrosis: more than just a scaffold. J Histochem Cytochem 67(9):643–661
England A, Chaney CP, Das A, Patel M, Malewska A, Armendariz D, Hon GC, Strand DW, Drake KA, Carroll TJ (2020) Identification and characterization of cellular heterogeneity within the developing renal interstitium. Development 147(15):dev90108
Barwinska D, El-Achkar TM, Ferreira RM, Syed F, Cheng YH, Winfree S, Ferkowicz MJ, Hato T, Collins KS, Dunn KW, Kelly KJ, Sutton TA, Rovin BH, Parikh SV, Philipps CL, Dagher PC, Eadon MT (2012) Molecular characterization of the human kidney interstitium in health and disease. Sci Adv 7(7):eabd3359
Minuth WW (2018) Reading first coordinates from the nephrogenic zone in human fetal kidney. Nephron 138(2):137–146
O’Brien LL, Combes AN, Short KM, Lindström NO, Whitney PH, Cullen-McEven LA, Ju A, Abdelhalim A, Michos O, Bertram JF, Smyth IA, Little MH, McMahon AP (2018) Wnt11 directs nephron progenitor polarity and motile behavior ultimately determining nephron endowment. Elife 7:e40392
Fetting JL, Guay JA, Karolak MJ, Iozzo RV, Adams C, Maridas DE, Brown AC, Oxburgh L (2014) FOXD1 promotes nephron progenitor differentiation by repressing decorin in the embryonic kidney. Development 141(1):17–27
Schumacher K, Strehl R, De Vries U, Groene HJ, Minuth WW (2002) SBA-positive fibers between the CD ampulla, mesenchyme and renal capsule. J Am Soc Nephrol 13:2446–2453
Schumacher K, Klar J, Wagner C, Minuth WW (2005) Temporal-spatial co-localisation of tissue transglutaminase (Tgase 2) and matrix metalloproteinase-9 (MMP-9) with SBA-positive microfibers in the embryonic kidney cortex. Cell Tissue Res 319:491–500
Strehl R, Kloth S, Aigner J, Steiner P, Minuth WW (1997) PCDAmp1, a new antigen at the interface of the embryonic collecting duct epithelium and the nephrogenic mesenchyme. Kidney Int 52(6):1469–1477
Strehl R, Trautner V, Kloth S, Minuth WW (1999) Existence of a dense reticular meshwork surrounding the nephron inducer in neonatal rabbit kidney. Cell Tissue Res 298(3):539–548
Strehl R, Minuth WW (2001) Partial identification of the mab (CD) Amp1 antigen at the epithelial-mesenchymal interface in the developing kidney. Histochem Cell Biol 116(5):389–396
Mounier F, Foidart JM, Gubler MC (1986) Distribution of extracellular matrix glycoproteins during normal development of human kidney An immunohistochemical study. Lab Invest 54(4):394–401
Minuth WW, Denk L (2012) Cell projections and extracellular matrix cross the interstitial interface within the renal stem/progenitor cell niche: accidental, structural or functional cues? Nephron Exp Nephrol 122(3):131–140
Minuth WW, Denk L (2013) The interstital interface within the renal stem/progenitor cell niche exhibits an unique microheterogeneous composition. Int J Mol Sci 14(7):13657–13669
Lindström NO, De Sena BG, Tran T, Ransick A, Suh G, Guo J, Kim AD, Parvez RK, Ruffins SW, Rutledge EA, Thornton ME, Grubbs B, McMahon JA, Smith AD, McMahon AP (2018) Progressive recruitment of mesenchymal progenitor cells reveals a time-dependent process of cell fate acquisition in mouse and human nephrogenesis. Dev Cell 45(5):651–660
Kao RM, Vasilyev A, Miyawaki A, Drummond IA, McMahon AP (2012) Invasion of distal nephron precursors associates with tubular interconnection during nephrogenesis. J Am Soc Nephrol 23(10):1682–1690
Zhang P, Gu L, Cong J, Zhang J, Thomsen JS, Andreasen A, Chang SJ, Deng SQ, Xing J, Zhai XY (2019) Morphology of the initial nephron-collecting duct connection in mice using computerized 3D tracing and electron microscopy. Biochem Biophys Res Commun 509(1):114–118
Sarkany B, Kovacs G (2021) Connecting tubules develop from the tip of the ureteric bud in the human kidney. Histochem Cell Biol 156(6):555–560
Miess C, Glashauser A, Denk L, deVries U, Minuth WW (2010) The interface between generating renal tubules and a polyester fleece in comparison to the interstitium of the developing kidney. Ann Biomed Eng 38(6):2197–2209
Schumacher A, Rookmaaker MB, Joles JA, Kramann R, Nguyen TQ, van Griensven M, LaPointe VLS (2021) Defining the variety of cell types in developing and adult human kidneys by single-cell RNA sequencing. Regen Med 6:45
Wilson SB, Little MH (2021) The origin and role of the renal stroma. Development 148(19):dev99886
I like to thank the Institute of Anatomy at the University of Regensburg for the substantial support.
Open Access funding enabled and organized by Projekt DEAL. The project was supported by the Emeriti Research Fund, University of Regensburg, D-93053 Regensburg, Germany.
Ethics approval and consent to participate
The author declares that the manuscript including generated data is in accordance with the Declaration of Helsinki, with national ethical legal regulations, and with the ethics of the University of Regensburg, Germany.
Consent for publication
The author declares no competing interests.
